مفتاح تيندا ذومنفذ جيجابت كمبيوتر مكتبي مفتاح معدني

Network standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab

LED Indicator
1* Power, 8* Link/Act

Interfaces
8*10/100/1000 Base-T Ethernet ports (Auto MDI/MDIX)

Transmission media
Recommended: CAT5/5e UTP or better

Fan quantity
N/A

Dimension
140.0mm×66.5mm×25.3 mm

Material
Metal

Level of protection
ESD:
Air discharge: ±8kV
Contact discharge: ±6kV

Forwarding mode
Store-and-forward

Switch capacity
16Gbps

Packet forwarding rate
12.00Mpps

Buffer
192KB

MAC address table
4K

Jombo frame
N/A

Power
Input: AC:190-240V
50/60Hz DC:9-12V

Power consumption
Max:<5W

Mounting
Desktop mounting: support
Wall mounting: support
Rack mounting:non-support

Environment
Operating temperature: 0°C - 45℃
Storage temperature: -40°C - 70°C
Operating humidity: (10% - 90%) RH, non-condensing
Storage humidity: (5% - 90%) RH, non-condensing

Protocols
CDMA/CD

MAC address learning
Auto-Learning and Auto-Aging

Funtions
plug-and-play
