كابل هيكفيجن 305 م CAT6 UTP الشبكة

Hikvision DS-1LN6U-W/CCA) 305 m CAT6 UTP Network Cable (CCA,0.565 mm)

• عام
• Core Color1 Blue & White/ Blue 2 Orange & White/ Orange,3 Green & White/ Green 4 Brown & White/ Brown,
• PackingCarton
• Carton Dimension41x41x24cm
• Packing Length(305±1.5)m
• Rip-CordYes
• Drain WireNo
• Sheath Physical PropertiesBefore Aging Tensile Strength (Mpa) ≥13.5, Elongation(%) ≥150,Aging Period(℃×hrs) 100℃×24h×7d,After Aging ,Tensile Strength(Mpa) ≥12.5, variance ratio:±25%, Elongation(%) ≥125, variance ratio:±20%,Cold bend(-20±2℃×4h) 8×Cable O.D.，No visible cracks,
• Electrical Characteristics (20℃)1.0-100.0MHz Impedance(Ω) 100±15,100 - 250MHz Impedance(Ω) 100±25,1.0-100.0MHz Delay Shew (ns/100m) ≤45,DC ResistanceΩ/100m) max 12,DC Conductor Resistance Unbalance(%) max 2,

• Conductor
• MaterialCCA（Copper content：27%）
• Nom.O.D.(Mm)0.585±0.01

• العزل
• MaterialSolid HDPE
• Diameter1.05±0.05mm

• Sheath
• Thickness0.50±0.05 mm
• External O.D.6.0±0.30 mm
• SurfaceClean, Frap, Satiation
• MaterialFR-PVC(complies RoHS)
• ColorWhite RAL9003

• Surface Printing
• Letter Height2.5±0.2mm
• ColorBlack
• Print Error & Space≤±0.5%，1m
